Product Characteristics：
1. Oil and electricity dual-use, provide more choices.
It can be powered by a switch or a built-in generator set or an external power supply.2. Low production and maintenance costs.
The operating system is stable and reliable. When using an external power supply, the unit production cost is significantly reduced, providing customers with more benefits.3. Advanced technology.
The cone crusher is driven by a motor, which has low energy consumption, high output, good grain shape of the finished product. The chamber is equipped with an overload protection system and adjusts the size of the discharge door by hydraulic pressure. A metal detection system is installed on the belt feeder to protect the chamber from metal.4. Can be put into use quickly with free installation
The folding mechanism is hydraulically folded, and it takes only a few minutes to change from the transport state to the working state, and there is no unnecessary installation.Technical parameter
| Application | Primary crushing of aggregate treatment, solid waste treatment, mining, etc., can use the generator set of the equipment, or set up the power grid |
|---|---|
| Hopper capacity | 9 m³ |
| Feeding height | 4000mm |
| Chamber inlet size | 1070×762 |
| Discharge door adjustment range высота разгрузки | 45mm-175mm |
| Main belt discharging height | 3350mm |
| Power | 240KW(normal power) |
| Max capacity | The data is based on crushing limestone and a bulk density of 1.6t/m3. The actual production depends on the composition of the raw materials, the size of the feed, and the pre-screening. |
| Weight | 52 t |
| Transportation size | 14500mm×3000mm×3600mm |
| Working size | 15850mm×4340mm×4000mm |
